Assets are a critical component of any business, and asset tracking is essential to ensure their safety and efficiency. By utilizing an asset tracker, businesses can get real-time updates on the location and condition of their assets, which can be extremely helpful in preventing theft and damage. Additionally, asset tracking can help businesses optimize their operations by reducing downtime, improving inventory management, and increasing overall efficiency.

Project Details

1. Main Features

◆Support OBD II /EOBD protocols

◆Support exclusive protocol of Japanese vehicle, Such as MITSUBISHI,HINO,ISUZU

◆Support commercial vehicle protocol,J1939,J1708.

◆50Hz 3-axis accelerator, real time uploading and restore vehicle accident process

◆Fast and precise GPS positioning ,Standard EMC HW(CISPR-25,ISO-7637,ISO-10605)

◆Real time position uploading ( support GPS-America, COMPASS-China, QZSS-Japan, GLONASS-Russia, Galileow-Europe, and these positioning system are optional)
◆Real time car status uploading, such as water temperature ,air intake pressure, RPM, speed, intake air temperature , air flow etc. And these function are optional.

◆Real time Mileage, fuel consumption, trip time uploading

◆Real time car DTCs uploading
◆Real time Alarms uploading: Speeding, Harsh acceleration/deceleration, Quick lane change, Sharp turn, Collision, over speed, low voltage, park w/o flameout, ignition/flameout, towed, Fault indication, Higher temperature, SOS, Dongle plug and unplug etc
◆Data uploading automatically after blind area

◆Remote Debugging function
◆SMS inquiry for car position link

2. Specification

Mechanical Parameter	Dimension	62mm（Length） x 50mm（Width） x 25mm（Height）
	Weight	100g
Interface		OBD interface： Support A/B Type Configuration interface ：Micro-USB SOS Button interface：MMCX
Support Diagnostic Protocol		Passenger：ISO15031 and Dedicated protocol of Japanese vehicle TOYOTA,NISSAN,MAZDA,HONDA,MITSUBISHI,SUBARU,SUZUKI,DAIHATSU) Commercial vehicle：J1939,J1708 and Dedicated protocol of MITSUBISHI,HINO,ISUZU
Power	Working Voltage	8-32VDC
	Working current	Max：<120mA@13.8DC,<80mA@27.6VDC Average( sleeping mode)：<10mA@12/24VDC
	Battery	3.7V/100mAH
Positioning system		GPS,QZSS,GLONASS,COMPASS,Galileow,A-GPS( Optional )
GPS Performance（GPS performance）		Receiver Channels：56 reacquisition Sensitivity：-160dBm position accuracy：2.5m CEP Cold Start：30s Hot Start：1s
GLONASS Performance（GLONASS performance）		Receiver Channels：56 reacquisition Sensitivity：-156dBm position accuracy：4.0m CEP Cold Start：32s Hot Start：1s
Actual Measurement 3D Positioning time		Cold Start：30s~120s Hot Start：3s~15s
Mode of data transmission		TCP/SMS
2G/3G		183G(SIM800C)： Quad-Band：GSM/GPRS 850/900/1800/1900MHz Certifications：CE,FCC,GCF,TA,ROHS,REACH,CTA,CCC 183W(LISA-U200)： Quad-Band：HSPA 800/850/900/1700/1900/2100 MHz, Quad-Band：GPRS/EDGE 850/900/1800/1900MHz Certifications：e4 ,R&TTE,CE,FCC SIM5360E(SIM5360E)： Dual-Band：UMTS/HSPA+ 900/2100MHz Quad-Band：GSM/GPRS/EDGE 850/900/1800/1900MHz Certifications：CE,GCF,ROHS,REACH,CCC,CTA SIM5320A(SIM5320A)： Dual-Band：WCDMA/HSDPA 850/1900MHz Quad-Band：GSM/GPRS/EDGE 850/900/1800/1900MHz Certifications：FCC,PTCRB,IC,ROHS,REACH Carrier Approvals：AT&T,Rogers SIM5320J(SIM5320J)： Dual-Band：UMTS/HSDPA 850(800)/2100MHz Quad-Band：GSM/GPRS/EDGE 850/900/1800/1900MHz Certifications：Telec,JATE Carrier Approvals：Docomo
3-axis accelerator		+/-16g
Storage		8M BYTE FLASH
Indication light		GPRS/GPS /OBD
Buzzer		System state/Alarm indication
Antenna	2G/3G	Built-in
	GPS	Built-in
Accessories optional		USB private wire，SOS extended cable
Enviromental Parameter	Operating Temperature	-30℃ ~ +70℃（Humidity 80%）
	Humidity	5%～95%（No Frosting）
